For a long time, infrared thermal imaging detection technology has
become an important means to ensure Industrial safety in developed
countries. Theapplication field includes electric power, metallurgy,
petro-chemistry, machinery,coal, traffic, fire control and national defense, etc. It can not only carries out real-time detection at high voltage, high current and high speed operation to perform real-time detection for production and
instrument but also need not power off the power supply, stop the machine or stop the production to find the potential problems and prevent occurrence of malfunction. The “non contact” modern detection technology
is safe, reliable and quick. It is a type of technical revolution compared with traditional contact detection method.
Performance index
Display screen |
2.8 ″ full angle TFT display creen |
Infrared image resolution |
220x160 |
Field angle |
35°×26° |
Temperature measurement rang |
-20℃ to 450℃ (-4°F to 842°F) |
Measurement accuracy |
±2℃/±2% (Greater than 300 ℃accuracy is ± 5%) |
Visible image resolution |
300,000 pixel |
LCD resolution |
320×240 |
Shortest focusing distance |
0.5M |
Shortest focusing distance |
70mK |
Emissivity |
Adjustable from 0.01 to 1.00 |
Frame rate of thermal images |
9Hz |
Wavelength coverage |
8-14um |
Focus mode |
Fixed |
Color palette |
Rainbow, iron oxide red, cold color, black & white, white & black |
Storage capacity |
Built-in 3G (above 20 thousand image stored) |
