Technical parameters
|
Technical indicators
|
Vibration acquisition
|
Piezoelectric ceramic accelerometer (shear type)
|
Measurement range
|
Acceleration：0.1~199.9m/s2
Velocity：0.1~199.9mm/s
Displacement：0.001~1.999mm
|
Measurement accuracy
|
Vibration displacement：0.01~0.02mm,
≤±10%. ≥0.02mm,≤±5%
Vibration velocity：0~2.0mm/s,
≤±10%.≥2.0mm/s,≤±5%
Vibration acceleration：0~2.0m/s2,
≤±10%.≥2.0m/s2,≤±5%
|
Frequency range of
acceleration measurement
|
High frequency
Low frequency
：1KHz～15KHz (HI)
Low frequency：20Hz～1KHz ( LO)
|
Frequency range of
speed measurement
|
20Hz～1KHz (LO)
|
Frequency range of
displacement measurement
|
20Hz～1KHz (LO)
|
LCD display
|
color display
|
Shuffle interval of
data display
|
1 second
|
Maximum groups of
data storage
|
7 groups
|
Power supply
|
1.5V AAA battery*2
|
Temperature range
for operation
|
0~40℃
|
Humidity range for
operation
|
30~90%RH
|
Size
|
180x54x30mm
|
Weight
|
250G(with batteries)
|
